PolyMide™ PA6-CF

PolyMide™ PA6-CF is a 20% carbon fiber reinforced Nylon 6 filament. The carbon fiber reinforcement provides significantly improved stiffness, strength and heat resistance with outstanding layer adhesion thanks to Fiber Adhesion™ Technology. PolyMide™ PA6-CF outperforms almost every 3D printing material, offering extreme durability and functionality while featuring a heat deflection temperature of 215°C.

High heat deflection temperature
Excellent isotropic rigidity
Dimensionally stable during printing

Color Range

Regular
SKU
PG03001
EAN
6938936711551
Color
Black
Diameter
1.75mm
Weight
0.5kg
SKU
PG03002
EAN
6938936711568
Color
Black
Diameter
2.85mm
Weight
0.5kg
SKU
PG03003
EAN
6938936712800
Color
Black
Diameter
1.75mm
Weight
2kg
SKU
PG03004
EAN
6938936712817
Color
Black
Diameter
2.85mm
Weight
2kg
Product Information Sheet
Technical Data Sheet

FAQ

What is the percentage of the carbon fiber content in PolyMide™ PA6-CF

It contains 20 wt% carbon fibers.

500g
2.0 kg

Specifications

PolyMide™ PA6-CF

MEchanical Properties

(XY)Young's Modulus (MPa):
7453.5 ± 656.2 MPa
ISO 527, GB/T 1040
(Z)Young's Modulus (MPa):
4354.5 ± 206.4 MPa
ISO 527, GB/T 1040
(XY)Tensile Strength:
105. ± 5.0 MPa
ISO 527, GB/T 1040
(Z)Tensile Strength:
67.7 ± 4.7 MPa
ISO 527, GB/T 1040
(XY)Elongation at break(%):
3.0 ± 0.3 %
ISO 527, GB/T 1040
(Z)Elongation at break(%)
2.5 ± 0.7 %
ISO 527, GB/T 1040
(XY)Bending Modulus (MPa):
8339.4 ± 369.4 MPa
ISO 178, GB/T 9341
(XY)Bending Strength (MPa):
169.0 ± 4.7 MPa
ISO 178, GB/T 9341
(XY)Charpy Impact Strength:
13.3 ± 0.5 kJ/m2
ISO 179, GB/T 1043

Thermal Properties

Glass Transition Temperature:
74.2 °C
DSC, 10°C/min
Melting Temperature:
74.2 °C
DSC, 10°C/min
Heat Deflection Temperature
(1.8MPa):
173.1 °C
ISO 75 1.8MPa
Heat Deflection Temperature
(0.45MPa)
215.2 °C
ISO 75 0.45MPa

Material Properties

Technology

Warp-Free technology

Fiber adhesion technology
