PolyMax™ PC-FR

PolyMax™ PC-FR is a fire-retardant PC filament displaying strength and toughness whilst also achieving a V0 score in the UL94 flame retardancy test. PolyMax™ PC-FR can reduce the intensity of a fire or slow/stop the spread of fire due to its self-extinguishing characteristics.

Flame retardant
Strong and tough
Heat resistant

Color Range

Regular
SKU
PC03001
EAN
6938936710578
Color
Black
Diameter
1.75mm
Weight
1kg
SKU
PC03002
EAN
6938936710585
Color
White
Diameter
1.75mm
Weight
1kg
SKU
PC03003
EAN
6938936712138
Color
Black
Diameter
2.85mm
Weight
1kg
SKU
PC03004
EAN
6938936712145
Color
White
Diameter
2.85mm
Weight
1kg
Product Information Sheet
Safety Data Sheet
Technical Data Sheet

Product Video

FAQ

Has PolyMax™ PC-FR been tested by a third-party?

Yes, PolyMax™ PC-FR has been tested by SGS-CSTC Standards Technical Services Co., Ldt.

Test Method:
IEC 60695-11-10:2013/Cor.1:2014 Method B

Result:
Classification: V-0

Does the FR affect the mechanical properties?

the FR additive will make the material less ductile which means a higher tensile strength and Young's modulus (more rigid). However the PC will maintain its great impact and high heat resistance.

1.0 kg

Specifications

PolyMax™ PC-FR

MEchanical Properties

(XY)Young's Modulus (MPa):
2634.1 ± 182.2 MPa
ISO 527, GB/T 1040
(Z)Young's Modulus (MPa):
2743.2 ± 72.2 MPa
ISO 527, GB/T 1040
(XY)Tensile Strength:
67.1 ± 4.5 MPa
ISO 527, GB/T 1040
(Z)Tensile Strength:
46.2 ± 4.8 MPa
ISO 527, GB/T 1040
(XY)Elongation at break(%):
3.5 ± 0.7 %
ISO 527, GB/T 1040
(Z)Elongation at break(%)
2.2 ± 0.3 %
ISO 527, GB/T 1040
(XY)Bending Modulus (MPa):
2518.2 ± 53.3 MPa
ISO 178, GB/T 9341
(XY)Bending Strength (MPa):
96.6 ± 1.3 MPa
ISO 178, GB/T 9341
(XY)Charpy Impact Strength:
11.7 ± 1.6 kJ/m
ISO 179, GB/T 1043

Thermal Properties

Glass Transition Temperature:
115 °C
DSC, 10°C/min
Melting Temperature:
115 °C
DSC, 10°C/min
Heat Deflection Temperature
(1.8MPa):
107 °C
ISO 75 1.8MPa
Heat Deflection Temperature
(0.45MPa)
110 °C
ISO 75 0.45MPa
Vicat Softening Temperature:
116 °C
ISO 306, GB/T 1633

Material Properties

Technology

Nano reinforcement Technology

SKU List

Close

* Please note that availability of certain SKUs may vary by location and not all products may be accessible at every reseller. We recommend contacting your local reseller for specific product availability in your region. You can also contact our regional sales team for more details.

Color Range

Color Range

Diameter

Diameter

Weight

Weight
  • SKU
    EAN/ UPC
    Product Name
    Diameter
    Color Range
    Color Name
    HEX
    Weight
    Product Code Description
    • PC03001
      6938936710578
      PolyMax™ PC-FR
      1.75mm
      Regular
      Black
      Not Yet
      1kg
      PolyMax™ PC-FR/ 1.75mm/ Regular/
       Black/
      1kg
    • PC03002
      6938936710585
      PolyMax™ PC-FR
      1.75mm
      Regular
      White
      Not Yet
      1kg
      PolyMax™ PC-FR/ 1.75mm/ Regular/
       White/
      1kg
    • PC03003
      6938936712138
      PolyMax™ PC-FR
      2.85mm
      Regular
      Black
      Not Yet
      1kg
      PolyMax™ PC-FR/ 2.85mm/ Regular/
       Black/
      1kg
    • PC03004
      6938936712145
      PolyMax™ PC-FR
      2.85mm
      Regular
      White
      Not Yet
      1kg
      PolyMax™ PC-FR/ 2.85mm/ Regular/
       White/
      1kg
