Series

PolyMax™ PC

PolyMax™ PC is an engineering PC filament combining excellent strength,toughness, heat resistance and printing quality. It outperforms many other choices of PC while still printing at a relatively low printing temperature. With a softening point of 113°C it can operate in demanding environments where impact resistance, heat resistance and vibrations occur.

Extremely tough PC
Heat resistant
Good layer adhesion

Color Range

Regular
SKU
PC02001
EAN
6938936710554
Color
Black
Diameter
1.75mm
Weight
0.75kg
SKU
PC02002
EAN
6938936710561
Color
White
Diameter
1.75mm
Weight
0.75kg
SKU
PC02005
EAN
6938936712442
Color
Grey
Diameter
1.75mm
Weight
0.75kg
SKU
PC02010
EAN
6938936713005
Color
Red
Diameter
1.75mm
Weight
0.75kg
SKU
PC02011
EAN
6938936713012
Color
Blue
Diameter
1.75mm
Weight
0.75kg
SKU
PC02003
EAN
6938936711773
Color
Black
Diameter
2.85mm
Weight
0.75kg
SKU
PC02004
EAN
6938936711780
Color
White
Diameter
2.85mm
Weight
0.75kg
SKU
PC02006
EAN
6938936712763
Color
White
Diameter
1.75mm
Weight
3kg
SKU
PC02007
EAN
6938936712770
Color
Black
Diameter
1.75mm
Weight
3kg
SKU
PC02014
EAN
6938936707608
Color
Grey
Diameter
1.75mm
Weight
3kg
SKU
PC02008
EAN
6938936712787
Color
White
Diameter
2.85mm
Weight
3kg
SKU
PC02009
EAN
6938936712794
Color
Black
Diameter
2.85mm
Weight
3kg
SKU
PC02012
EAN
6938936707394
Color
Black
Diameter
1.75mm
Weight
5kg
SKU
PC02013
EAN
6938936707400
Color
Black
Diameter
2.85mm
Weight
5kg

FAQ

What is the best surface adhesive for PolyMax™ PC?

In our experience we had excellent experience with Magigoo PC. This special glue allows great adhesion when the build plate is hot and easy release when the build plate cools down.

Does PolyMax™ PC need to be annealed?

Annealing is the process of heating up the printed parts at a certain temperature for a certain period of time. You can anneal PolyMax™ PC at 90_ for 2h.

The purpose of annealing PolyMax™ PC is to release the internal stress which accumulates during the printing process. This internal stress can creates micro cracks over time and weaken the part.

(NOTE: In the case of semi-crystalline polymers such as Nylon, annealing purpose is mainly to crystalize the material for better mechanical and thermal properties)

Is this impact resistant, like for rc car parts?

Yes, PolyMax™ PC is a toughness enhanced PC product, the charpy impact strength is 22KJ/_.

750g
3.0 kg
5.0 kg

Specifications

PolyMax™ PC

MEchanical Properties

(XY)Young's Modulus (MPa):
2435.5 ± 63.6 MPa
ISO 527, GB/T 1040
(Z)Young's Modulus (MPa):
2149.8 ± 119.9 MPa
ISO 527, GB/T 1040
(XY)Tensile Strength:
53.4 ± 0.6 MPa
ISO 527, GB/T 1040
(Z)Tensile Strength:
41.4 ± 1.5 MPa
ISO 527, GB/T 1040
(XY)Elongation at break(%):
4.5 ± 0.4 %
ISO 527, GB/T 1040
(Z)Elongation at break(%)
2.8 ± 0.2 %
ISO 527, GB/T 1040
(XY)Bending Modulus (MPa):
2050.1 ± 79.4 MPa
ISO 178, GB/T 9341
(XY)Bending Strength (MPa):
81.3 ± 1.5 MPa
ISO 178, GB/T 9341
(XY)Charpy Impact Strength:
21.3 ± 1.7 kJ/m2
ISO 179, GB/T 1043

Thermal Properties

Glass Transition Temperature:
113 °C
DSC, 10°C/min
Melting Temperature:
113 °C
DSC, 10°C/min
Heat Deflection Temperature
(1.8MPa):
99.3 °C
ISO 75 1.8MPa
Heat Deflection Temperature
(0.45MPa)
114.1 °C
ISO 75 0.45MPa
Vicat Softening Temperature:
116.9 °C
ISO 306, GB/T 1633

Material Properties

Technology

Nano reinforcement Technology

SKU List

Close

* Please note that availability of certain SKUs may vary by location and not all products may be accessible at every reseller. We recommend contacting your local reseller for specific product availability in your region. You can also contact our regional sales team for more details.

Color Range

Color Range

Diameter

Diameter

Weight

Weight
  • SKU
    EAN/ UPC
    Product Name
    Diameter
    Color Range
    Color Name
    HEX
    Weight
    Product Code Description
    • PC02001
      6938936710554
      PolyMax™ PC
      1.75mm
      Regular
      Black
      Not Yet
      0.75kg
      PolyMax™ PC/ 1.75mm/ Regular/
       Black
      0.75kg
    • PC02002
      6938936710561
      PolyMax™ PC
      1.75mm
      Regular
      White
      Not Yet
      0.75kg
      PolyMax™ PC/ 1.75mm/ Regular/
       White
      0.75kg
    • PC02005
      6938936712442
      PolyMax™ PC
      1.75mm
      Regular
      Grey
      Not Yet
      0.75kg
      PolyMax™ PC/ 1.75mm/ Regular/
       Grey
      0.75kg
    • PC02010
      6938936713005
      PolyMax™ PC
      1.75mm
      Regular
      Red
      Not Yet
      0.75kg
      PolyMax™ PC/ 1.75mm/ Regular/
       Red
      0.75kg
    • PC02011
      6938936713012
      PolyMax™ PC
      1.75mm
      Regular
      Blue
      Not Yet
      0.75kg
      PolyMax™ PC/ 1.75mm/ Regular/
       Blue
      0.75kg
    • PC02003
      6938936711773
      PolyMax™ PC
      2.85mm
      Regular
      Black
      Not Yet
      0.75kg
      PolyMax™ PC/ 2.85mm/ Regular/
       Black
      0.75kg
    • PC02004
      6938936711780
      PolyMax™ PC
      2.85mm
      Regular
      White
      Not Yet
      0.75kg
      PolyMax™ PC/ 2.85mm/ Regular/
       White
      0.75kg
    • PC02006
      6938936712763
      PolyMax™ PC
      1.75mm
      Regular
      White
      Not Yet
      3kg
      PolyMax™ PC/ 1.75mm/ Regular/
       White
      3kg
    • PC02007
      6938936712770
      PolyMax™ PC
      1.75mm
      Regular
      Black
      Not Yet
      3kg
      PolyMax™ PC/ 1.75mm/ Regular/
       Black
      3kg
    • PC02014
      6938936707608
      PolyMax™ PC
      1.75mm
      Regular
      Grey
      Not Yet
      3kg
      PolyMax™ PC/ 1.75mm/ Regular/
       Grey
      3kg
    • PC02008
      6938936712787
      PolyMax™ PC
      2.85mm
      Regular
      White
      Not Yet
      3kg
      PolyMax™ PC/ 2.85mm/ Regular/
       White
      3kg
    • PC02009
      6938936712794
      PolyMax™ PC
      2.85mm
      Regular
      Black
      Not Yet
      3kg
      PolyMax™ PC/ 2.85mm/ Regular/
       Black
      3kg
    • PC02012
      6938936707394
      PolyMax™ PC
      1.75mm
      Regular
      Black
      Not Yet
      5kg
      PolyMax™ PC/ 1.75mm/ Regular/
       Black
      5kg
    • PC02013
      6938936707400
      PolyMax™ PC
      2.85mm
      Regular
      Black
      Not Yet
      5kg
      PolyMax™ PC/ 2.85mm/ Regular/
       Black
      5kg
